Alan Grove Engine Brackets

Alternator bracket kits are designed to be used with GM type external or internal regulated alternators.These also fit the new CS130 style alternators.Designed for cars with low hood clearance such as Corvette,Camaro and 50's or 60's cars and trucks with wide engine compartment.Will fit 1969 and newer heads including the Vortec cast iron head.Use with AG-134R or AG-135R A/C compressor bracket.
LOW PROFILE
SMALL BLOCK
LONG WATER PUMP
LEFT SIDE MOUNT

This bracket is designed for a Chevrolet Saginaw non-metric power steering pump with an attached reservoir.This style pump was used in most Chevrolet models into the early 1980'sThis style bracket will clear the alternator belt no matter where the alternator is mounted .Short water pump applications are normally driven off a add on third crankshaft pulley.
SMALL BLOCK
SHORT WATER PUMP

This bracket bolts to the front of the engine block and the water pump boss.This style bracket will mount the pump in approximately the same location as factory without using the head or exhaust bolts.This bracket will require the use of a power steering pump with two mounting locations on the canister.
SMALL BLOCK
LONG WATER PUMP

This bracket is designed for a Chevrolet Saginaw non-metric power steering pump with an attached reservoir.This style pump was used in most Chevrolet models into the early 1980'sThis style bracket will clear the alternator belt no matter where the alternator is mounted .Short water pump applications are normally driven off a add on third crankshaft pulley.
BIG BLOCK
SHORT WATER PUMP

This bracket is a combination front motor mount and power steering pump bracket designed specifically for 1955-57 Chevrolet cars and 1955-59 trucks.This bracket will replace the original left side engine mount and will work with up to an 8" balancer. This bracket will require the use of a 1958 or later engine block because the bracket will use bolt holes located in the side engine mount boss.(also see note below)This bracket is designed to be used with a Chevrolet Saginaw non-metric power steering pump with attached reservoir.THIS BRACKET IS FOR FRONT STYLE MOUNTS ONLY,NOT FOR SIDE ENGINE MOUNT CONVERSIONS.
SMALL BLOCK
SHORT WATER PUMP
NOTE: This bracket can be used with a stock 55-57 block with the use of part # AG-404L-1.

This bracket is necessary when using Part # AG-404L and an original 1955-57 engine block with no side motor mount holes.
NOTE: This bracket is of private manufacture.

This style bracket bolt to the front of the engine block and to the water pump boss.Positions the pump in approximately the same location as factory.
BIG BLOCK
LONG WATER PUMP

This is a combination bracket set specifically designed for 1964-68 Chevelle's with a short water pump small block. Designed to use standard case GM alternator, Chevrolet Saginaw non-metric power steering pump with attached reservoir. Brackets bolt to water pump and the first and third exhaust manifold bolt. May not work with some headers or will require modification to clear front header tube. Works with tall valve covers. Use part # AG-113R for A/C bracket and a Sanden 508 A/C compressor.

SMALL BLOCK

SHORT WATER PUMP

This is a combination bracket set specifically designed for 1964-68 Chevelle's with a short water pump big block. Designed to use standard case GM alternator, Chevrolet Saginaw non-metric power steering pump with attached reservoir. Bolts to top water pump bolt and two points on the outer cylinder head. Works with tall valve covers. Use with part #AG-118R A/C brackets and Sanden 508 compressor.

BIG BLOCK

SHORT WATER PUMP
